Inder Monga

Large scientific collaborations often share huge volumes of data around the world. Consequently a significant amount of network bandwidth is needed for data replication and data access. Users in the same region may possibly share resources as well as data, especially when they are working on related topics with similar datasets. In this work, we study the network traffic patterns and resource utilization for scientific data caches connecting European networks to the US. We explore the efficiency of resource utilization, especially for network traffic which consists mostly of transatlantic data transfers, and the potential for having more caching node deployments. Our study shows that these data caches reduced network traffic volume by 97% during the study period. This demonstrates that such caching nodes are effective in reducing wide-area network traffic.

Large community of high-energy physicists share their data all around world making it necessary to ship a large number of files over wide-area networks. Regional disk caches such as the Southern California Petabyte Scale Cache have been deployed to reduce the data access latency. We observe that about 94% of the requested data volume were served from this cache, with-out remote transfers, between Sep. 2022 and July 2023. In this paper, we show the predictability of the resource utilization by exploring the trends of recent cache usage. The time series based prediction is made with a machine learning approach and the prediction errors are small relative to the variation in the input data. This work would help understanding the characteristics of the resource utilization and plan for additional deployments of caches in the future.

Large scientific collaborations often have multiple scientists accessing the same set of files while doing different analyses, which create repeated accesses to the large amounts of shared data located far away. These data accesses have long latency due to distance and occupy the limited bandwidth available over the wide-area network. To reduce the wide-area network traffic and the data access latency, regional data storage caches have been installed as a new networking service. To study the effectiveness of such a cache system in scientific applications, we examine the Southern California Petabyte Scale Cache for a high-energy physics experiment. By examining about 3TB of operational logs, we show that this cache removed 67.6% of file requests from the wide-area network and reduced the traffic volume on wide-area network by 12.3TB (or 35.4%) an average day. The reduction in the traffic volume (35.4%) is less than the reduction in file counts (67.6%) because the larger files are less likely to be reused. Due to this difference in data access patterns, the cache system has implemented a policy to avoid evicting smaller files when processing larger files. We also build a machine learning model to study the predictability of the cache behavior. Tests show that this model is able to accurately predict the cache accesses, cache misses, and network throughput, making the model useful for future studies on resource provisioning and planning.

The Software-defined network for End-to-end Networked Science at Exascale (SENSE) research project is building smart network services to accelerate scientific discovery in the era of ‘big data’ driven by Exascale, cloud computing, machine learning and AI. The project’s architecture, models, and demonstrated prototype define the mechanisms needed to dynamically build end-to-end virtual guaranteed networks across administrative domains, with no manual intervention. In addition, a highly intuitive ‘intent’ based interface, as defined by the project, allows applications to express their high-level service requirements, and an intelligent, scalable model-based software orchestrator converts that intent into appropriate network services, configured across multiple types of devices. The significance of these capabilities is the ability for science applications to manage the network as a firstclass schedulable resource akin to instruments, compute, and storage, to enable well defined and highly tuned complex workflows that require close coupling of resources spread across a vast geographic footprint such as those used in science domains like high-energy physics and basic energy sciences.

This paper presents an implementation of the lambda architecture design pattern to construct a data-handling backend on Amazon EC2, providing high throughput, dense and intense data demand delivered as services, minimizing the cost of the network maintenance. This paper combines ideas from database management, cost models, query management and cloud computing to present a general architecture that could be applied in any given scenario where affordable online data processing of Big Datasets is needed. The results are presented with a case study of processing router sensor data on the current ESnet network data as a working example of the approach. The results showcase a reduction in cost and argue benefits for performing online analysis and anomaly detection for sensor data

We evaluate a WAN-virtualization framework in terms of delay and scalability and demonstrate that adding a virtual layer between the physical topology and the end-user brings significant advantages and tolerable delays

Wide area networks (WAN) forward traffic through a mix of packet and optical data planes, composed by a variety of devices from different vendors. Multiple forwarding technologies and encapsulation methods are used for each data plane (e.g. IP, MPLS, ATM, SONET, Wavelength Switching). Despite standards defined, the control planes of these devices are usually not interoperable, and different technologies are used to manage each forwarding segment independently (e.g. OpenFlow, TL-1, GMPLS). The result is lack of coordination between layers and inefficient resource usage. In this paper we discuss the design and implementation of a system that uses unmodified OpenFlow to optimize network utilization across layers, enabling practical bandwidth virtualization. We discuss strategies for scalable traffic monitoring and to minimize losses on route updates across layers. We explore two use cases that benefit from multi-layer bandwidth on demand provisioning. A prototype of the system was built open using a traditional circuit reservation application and an unmodified SDN controller, and its evaluation was per-formed on a multi-vendor testbed.

http://blog.infinera.com/2014/09/05/henrique-rodrigues-wins-best-student-paper-at-ieee-hot-interconnects-for-infinerabrocadeesnet-multi-layer-sdn-demo/

http://esnetupdates.wordpress.com/2014/09/05/esnet-student-assistant-henrique-rodrigues-wins-best-student-paper-award-at-hot-interconnects/

Best Student Paper

Several studies have proposed job migration over the wide area network (WAN) to reduce the energy of networks of datacenters by taking advantage of different electricity prices and load demands. Each study focuses on only a small subset of network parameters and thus their results may have large errors. For example,  datacenters usually have long-term power contracts instead of paying market prices. However, previous work neglects these contracts, thus overestimating the energy savings by 2.3x. We present a comprehensive approach to minimize the energy cost of networks of datacenters by modeling performance of the workloads, power contracts, local renewable energy sources, different routing options for WAN and future router technologies. Our method can reduce the energy cost of datacenters by up to 28%, while reducing the error in the energy cost estimation by 2.6x.

ESnet provides a platform for moving large data sets and accelerating worldwide scientific collaboration. It provides high-bandwidth, reliable connections that link scientists at national laboratories, universities and other research institutions, enabling them to collaborate on some of the world's most important scientific challenges including renewable energy sources, climate science, and the origins of the universe.

ESnet has embarked on a major project to provide substantial visibility into the inner-workings of the network by aggregating diverse data sources, exposing them via web services, and visualizing them with user-centered interfaces. The portal’s strategy is driven by understanding the needs and requirements of ESnet’s user community and carefully providing interfaces to the data to meet those needs. The 'MyESnet Portal' allows users to monitor, troubleshoot, and understand the real time operations of the network and its associated services.

This paper will describe the MyESnet portal and the process of developing it. The data for the portal comes from a wide variety of sources: homegrown systems, commercial products, and even peer networks. Some visualizations from the portal are presented highlighting some interesting and unusual cases such as power consumption and flow data. Developing effective user interfaces is an iterative process. When a new feature is released, users are both interviewed and observed using the site. From this process valuable insights were found concerning what is important to the users and other features and services they may also want. Open source tools were used to build the portal and the pros and cons of these tools are discussed.
